Cabinet and arm mounting
The cabinet carries the arm pivot and front equipment panel.
VEHICLE ACCESS
DZ-73C Boom Barrier
A champagne-gold cabinet with a straight or fence arm for vehicle entrances. Select the arm configuration around the lane and overhead space.
- Arm configurations
- Straight, fence and cranked configurations
ARM & CABINET PLANNING
Choose the arm for the space above the lane.
The cabinet is installed beside the traffic route. The selected straight, fence or articulated arm determines the movement envelope that needs to remain clear.
Clear lane
Measure the clear vehicle lane independently from the cabinet footprint. Include the required opening direction.
Raised arm
Check the full raised-arm envelope against ceilings, trees and surrounding structures. Articulated arms require their own layout.
Detection & control
Specify the recognition terminal, vehicle detection and control interfaces together. These are agreed configuration items.
STRUCTURE & DETAILS
Straight or fence arm, in a gold cabinet.
The original product views show the cabinet and arm connection, plus the two displayed arm configurations. Select the arm around the lane width and available headroom.
Fence-arm configuration
Original manufacturer artwork shows the same cabinet family with a fence arm. Confirm arm length and installation space with the selected configuration.
ENTRANCE PLANNING
Leave space for the complete movement.
Check the lane width, cabinet position and overhead clearance before selecting the arm. Share a site plan or photographs so the installation arrangement can be reviewed.
Build a complete systemMODEL SPECIFICATIONS
DZ-73C specifications
| Parameter | Specification |
|---|---|
| Model | DZ-73C |
| Arm configurations | Straight, fence and cranked configurations |
The quotation confirms the supplied equipment and configuration.
PRODUCT QUESTIONS
Before you specify.
What changes when I choose the fence arm?
The arm carries additional vertical members beneath its main rail. The straight and fence choices update the product image and enquiry; length and movement clearance are checked for the selected arm.
Can I request an articulated arm?
The catalogue also shows articulated straight and articulated fence arrangements. Include the available overhead clearance and required arm configuration in the site enquiry.
How is the final cabinet size confirmed?
The supplied cabinet, base and fixing dimensions are confirmed with the quotation and installation information. Do not set out foundations from a product photograph.
Can DZ-73C be paired with an ANPR terminal?
Yes, it can be specified within a vehicle access system. Select the recognition terminal, detection equipment and parking-control requirements for the lane.
YOUR PROJECT
Request a DZ-73C quotation.
Share the equipment quantity, destination country and site requirements.
DZ-73C Boom BarrierStraight armConfiguration confirmed in your quotation
